Send us your chips and we handle the rest
10+ years of R&D experience in silicon photonics, lasers, and optical communications.
Take advantage of the fastest time to production and consult your results in real time as they become available.
One chip at a time
Choose from a wide variety of measurements either standard (IV Curves, …) or custom. For all sorts of chip types including SOI, SiN, III-V, LNOI, etc.
As many individual chips as required. Get knowledge on assorted sets of chips, see performance variation on incremental designs, or even identical units.
Up to 300 mm
Evaluation of full production wafers and multi-project wafers. Get location-based yield variation data and learn about the accuracy of the fabrication process.
For all your common applications
Get accurate RF measurements of your devices
Discover heat-related impacts on your electro-optic components
Side or in-trench
Up to 4 probes simultaneously
Auto-alignment on devices, active tuning, use of predictive models to eliminate redundant tests. Deterministic position tracking for advanced navigation assistance.
Our cloud-based data storage solution enables real-time consultation of results as they become available. Analyse your data while we’re testing, no need to wait for a report.
Automated post-treatment and analysis of accumulated data. Build custom predictive models based off previous runs. Get wafer-scale variation maps and updatable reports that include the latest data points.
Design For Test
Minimize test time by employing tested-and-proven design choices
R&D Chip Design
Our experience is your new tool to bring your ideas into functional prototypes
Ramp up your testing capacity to transition from R&D designs to full production
Get a Quote
Want more information on how we can help characterizing your products? Enter your inquiry below and we'll get back to you promptly.
